General Specification
► Tiny-Bus® Modular
Expansion Solution with SiS VB (Video Bridge) and PCI
interface.
►
Onboard SiS VB (Video Bridge) based 301 DVI transmitter
and TV-out encoder.
►
DVI interface supports up to 1600 x 1200 of resolution.
►
TV-out interface supports AV / S-Video with NTSC / PAL
mode.
►
Onboard Type-IIIA/B mini-PCI expansion interface.
External / Internal
Connector
►
External DVI connector.
►
External composite AV / S-Video TV-out connector.
►
Onboard 124-pin mini-PCI Type-III socket. |
