General Specification
► Tiny-Bus® Modular
Expansion Solution with SiS VB (Video Bridge) and PCI
interface.
►
Onboard SiS VB (Video Bridge) based 302ELV LVDS
transmitter.
►
Single / dual channel 18-/24-bit LVDS TFT LCD interface
with 1920 x 1600 of resolution.
►
Onboard Type-IIIA/B mini-PCI expansion interface.
External / Internal
Connector
►
Onboard 40-pin Hirose DF13-40DP-1.25V LVDS connector.
►
Onboard 124-pin mini-PCI Type-III socket. |
